Frigidaire Gallery Dishwasher Not Draining

A malfunctioning dishwasher can be a real inconvenience, especially when it fails to drain properly. If you own a Frigidaire Gallery Dishwasher and are experiencing drainage issues, don’t worry – this guide will walk you through a step-by-step troubleshooting process to help identify and resolve the problem.

1. Check for Common Obstructions


b. Filter and Spray Arm Inspection: Check the dishwasher’s filter, located at the bottom, for any debris, food particles, or foreign objects. Also, inspect the spray arm for any blockages that might be impeding water flow.

c. Drain Basket Examination: Beneath the lower spray arm, there’s a drain basket. Make sure it’s free from debris that could obstruct water drainage.

2. Examine the Drain Hose

a. Disconnect the Power: Safety first! Unplug the dishwasher or turn off the circuit breaker to cut the power.

b. Locate the Drain Hose: The drain hose is usually located beneath the dishwasher. It’s a flexible tube that carries the wastewater out. Ensure it’s not kinked, pinched, or twisted, as this can restrict water flow.

c. Check for Clogs: Disconnect the drain hose from the sink drain or garbage disposal and examine it for any clogs or blockages. Use a pipe cleaner or a long, flexible brush to clear any obstructions.

d. Gravity Drain Test: If the hose appears clear, try a gravity drain test. Place the disconnected end of the hose into a bucket or basin, then turn the dishwasher on. If it drains into the bucket, the issue might lie with the sink drain or disposal.

3. Inspect the Air Gap (if applicable)

Some dishwashers are equipped with an air gap, which prevents wastewater from flowing back into the dishwasher. It’s usually located on the countertop near the sink. If you have one, ensure it’s not clogged. Remove the cover and clean any debris.

4. Check the Garbage Disposal (if connected)

If your dishwasher drains through the garbage disposal, inspect it for clogs. Run the garbage disposal to clear any potential blockages. Ensure the knockout plug inside the disposal (if not removed during installation) has been removed to allow drainage.

5. Examine the Drain Pump

The drain pump is responsible for pushing water out of the dishwasher. If it’s malfunctioning, it can cause drainage problems.

a. Access the Drain Pump: To reach the drain pump, you may need to remove the lower panel of the dishwasher. Refer to your owner’s manual for specific instructions on accessing the pump.

b. Check for Debris: Inspect the drain pump for any debris, such as broken glass or food particles. If you find any, remove it carefully.

c. Test the Drain Pump: While the dishwasher is disconnected from power, use a multimeter to test the drain pump for continuity. If it fails this test, the pump may need to be replaced.

6. Evaluate the Drain Solenoid

Some dishwashers have a drain solenoid that controls the drain valve. If this component is faulty, it can prevent the dishwasher from draining.

a. Locate the Drain Solenoid: Refer to your dishwasher’s manual to find the drain solenoid. It’s typically situated near the drain pump.

b. Test the Solenoid: Use a multimeter to test the drain solenoid for continuity. If it’s not functioning correctly, it might need replacement.

7. Call for Professional Help

If none of the above steps resolves the issue, it’s time to call in a professional appliance technician. They have the expertise and tools to diagnose and fix more complex problems like a malfunctioning control board, faulty sensor, or a blocked drain line deeper within the appliance.

8. Reset the Dishwasher

Sometimes, a simple reset can clear up minor glitches causing drainage problems.

a. Power Cycle: Turn off the dishwasher and unplug it or switch off the circuit breaker for a few minutes. Then, plug it back in or turn the breaker on. This can help reset the dishwasher’s electronics.

b. Factory Reset: Refer to your owner’s manual to perform a factory reset if your dishwasher has this option. This can restore the dishwasher’s settings to their default configuration.

9. Check for Proper Installation

Improper installation can lead to drainage issues. Ensure that your dishwasher is installed correctly, with proper alignment and connections.

a. Leveling: Make sure the dishwasher is level. If it’s tilted forward or backward, water might not drain properly. Adjust the leveling feet as needed.

b. High Loop in Drain Hose: The drain hose should be installed with a high loop under the sink. This prevents backflow of water from the sink into the dishwasher.

10. Investigate Error Codes

Many modern dishwashers, including the Frigidaire Gallery models, have error code systems to diagnose issues. Refer to your owner’s manual to decipher any error codes displayed on the control panel. This can provide valuable insight into what might be causing the drainage problem.

11. Consider Water Temperature and Detergent

Inadequate water temperature and improper detergent usage can contribute to drainage problems.

a. Water Temperature: Check if your water heater is set to an appropriate temperature (around 120°F or 49°C). Insufficiently hot water can hinder the dishwasher’s cleaning and draining performance.

b. Detergent Type and Amount: Ensure you’re using the right type and amount of dishwasher detergent recommended by the manufacturer. Using too much detergent or the wrong kind can lead to excessive suds that impede drainage.

12. Preventative Maintenance

Regular maintenance can help prevent drainage issues in the future.

a. Monthly Cleaning: Run a maintenance cycle with a dishwasher cleaner to keep the interior components clean and free from buildup.

b. Rinse Dishes: Scrape off excess food from dishes before loading them into the dishwasher. This prevents debris from clogging the drain system.

c. Soft Water Consideration: If you have soft water, you might need to adjust detergent amounts, as excessive suds from soft water can contribute to drainage problems.

13. Seek Manufacturer Support

If your Frigidaire Gallery Dishwasher is still not draining despite your efforts, don’t hesitate to contact Frigidaire’s customer support. They can provide guidance, troubleshooting tips, and recommendations for authorized service technicians in your area.

Remember that while some drainage issues can be resolved through DIY troubleshooting, more complex problems may require professional expertise. Prioritize your safety and the integrity of your appliance when attempting any repairs or inspections.

By following these additional steps, you’ll have a comprehensive guide to help you troubleshoot and resolve drainage issues with your Frigidaire Gallery Dishwasher.


Common Causes

Clogged Drain HoseBlockage in the drain hose prevents water flow.
Garbage Disposal IssueDisposal connection may hinder drainage.
Filter BlockageDirty or clogged filters restrict water flow.
Pump FailureMalfunctioning pump can’t remove wastewater.
Faulty Drain ValveDrain valve not opening properly to release water.

Troubleshooting Steps

Check for ObstructionsInspect the drain hose and filter for blockages.
Test the Garbage DisposalEnsure it’s working correctly.
Clean the FiltersRemove and clean the dishwasher’s filters.
Examine the PumpTest the pump for functionality or blockages.
Inspect Drain ValveEnsure the valve opens and closes as needed.

Potential Solutions

Unclog Drain HoseRemove any debris or blockages from the hose.
Fix Garbage DisposalRepair or replace the disposal if necessary.
Filter MaintenanceRegularly clean or replace the dishwasher filters.
Pump ReplacementReplace the pump if it’s damaged or malfunctioning.
Repair or Replace ValveFix or replace the drain valve if faulty.

Additional Tips

Use a Drain CleanerOccasionally use a dishwasher-safe drain cleaner.
Run Hot Water FirstFlush the sink with hot water before starting.
Load Dishes ProperlyArrange dishes to prevent obstruction of spray arms.
Regular MaintenanceClean and maintain your dishwasher regularly.
Professional HelpIf issues persist, consult a technician for repair.

Prevention Tips

Scrape PlatesRemove excess food from dishes before loading.
Rinse DishesPre-rinse heavily soiled dishes before loading.
Use High-Quality DetergentQuality detergent aids in proper draining.
Avoid OverloadingDon’t overload the dishwasher to allow proper flow.
Check InstallationEnsure proper installation for efficient draining.
