Maytag Bravos Dryer Heating Element Replacement

Is your Maytag Bravos dryer no longer producing heat, leaving your laundry damp and your frustration levels high? It might be time to replace the heating element. The heating element is a critical component of your dryer, responsible for generating the heat needed to dry your clothes effectively. In this guide, we’ll walk you through the process of replacing the heating element in your Maytag Bravos dryer, step by step.

Tools and Materials You’ll Need


Safety should be a top priority when working with electrical appliances. Before you begin:

  1. Disconnect Power: Unplug the dryer from the electrical outlet or turn off the circuit breaker to ensure there’s no power supply.
  2. Wait for Cool Down: Allow the dryer to cool down completely. The heating element can be extremely hot, and working on it while it’s still hot is dangerous.

Steps to Replace the Heating Element

Now, let’s go through the steps to replace the heating element:

Step 1: Access the Heating Element

  1. Locate the dryer’s lint filter and remove it.
  2. Remove the screws that secure the lint filter housing to the dryer’s top panel. Once removed, you should be able to lift the top panel.

Step 2: Disconnect Wires

  1. Inside the dryer, you’ll find the heating element assembly. It’s usually located at the rear of the dryer.
  2. Carefully disconnect the wires from the heating element terminals. Make sure to note which wire goes where or take a photo for reference.

Step 3: Remove the Old Heating Element

  1. Using your screwdriver or nut driver, remove the screws or nuts that hold the heating element assembly in place.
  2. Carefully lift out the old heating element.

Step 4: Install the New Heating Element

  1. Insert the new heating element into the same position where you removed the old one.
  2. Secure the heating element with the screws or nuts you removed earlier.

Step 5: Reconnect Wires

  1. Reconnect the wires to the heating element terminals, ensuring you attach them to the correct terminals as noted or photographed earlier.

Step 6: Reassemble the Dryer

  1. Lower the top panel of the dryer back into place and secure it by reattaching the screws that hold the lint filter housing.
  2. Reinsert the lint filter.

Step 7: Restore Power

  1. Plug the dryer back into the electrical outlet or turn the circuit breaker back on.

Step 8: Test the Dryer

  1. Turn on the dryer and select a heat setting. Allow it to run for a few minutes to ensure the heating element is functioning correctly.

Troubleshooting Tips

1. Testing the Heating Element

Before you start the replacement, it’s a good idea to test the old heating element to confirm that it’s the source of the problem. You can do this with a multimeter set to measure resistance (ohms). Here’s how:

  • Disconnect the wires from the heating element terminals.
  • Place the multimeter probes on the terminals of the heating element.
  • If the multimeter reads infinite resistance (OL), the heating element is likely faulty and needs replacement. If it reads a low resistance value, the element might be working fine, and the issue could be elsewhere in the dryer.

2. Clean the Dryer Vent

Sometimes, poor drying performance can be attributed to a clogged dryer vent. Before replacing the heating element, it’s a good practice to clean the dryer vent system thoroughly. A clogged vent can restrict airflow, causing longer drying times and potentially overheating the heating element.

3. Thermal Fuse and Thermostat Check

If your heating element is constantly burning out or not producing heat, it may be due to a malfunctioning thermal fuse or thermostat. These safety components can shut off the heating element if they detect overheating. Check these components for continuity with a multimeter to ensure they are functioning correctly.

Buying the Right Heating Element

When purchasing a replacement heating element, ensure it’s compatible with your specific Maytag Bravos dryer model. Match the part number or model number to the one in your dryer’s manual or on the old heating element itself. Additionally, consider buying a high-quality replacement part from a reputable supplier to ensure longevity and safety.

Safety Reminder

Working with electrical appliances carries inherent risks, so always prioritize safety:

  • Disconnect Power: Reiterate the importance of unplugging the dryer or turning off the circuit breaker before starting any repair work.
  • Wear Protective Gear: In addition to gloves and safety glasses, consider wearing a long-sleeved shirt to protect your arms from sharp edges inside the dryer.
  • Ventilation: Perform the repair in a well-ventilated area to avoid inhaling dust or debris.

When to Call a Professional

While replacing a heating element is a manageable DIY task for many, there are situations where it’s best to call a professional:

  • If you’re not comfortable working with electrical components.
  • If your dryer is still under warranty, attempting a DIY repair may void the warranty.
  • If you’re unable to diagnose the problem correctly or if multiple components appear to be malfunctioning.

Regular Maintenance

To extend the lifespan of your dryer and heating element, consider the following maintenance tips:

  • Clean the lint filter after every use to prevent lint buildup.
  • Periodically clean the dryer vent and exhaust duct to ensure proper airflow.
  • Avoid overloading the dryer, as this can strain the heating element and other components.

Remember that regular maintenance can prevent heating element issues and keep your dryer running efficiently for years to come.


Maytag Bravos Dryer Models

Model NumberDryer TypeCapacity (cu. ft.)Energy SourceHeating Element Type
MGDX655DWGas7.0Natural GasCoil Heating Element
MEDX655DWElectric7.0ElectricCoil Heating Element
MGDB755DWGas7.0Natural GasCoil Heating Element
MEDB755DWElectric7.0ElectricCoil Heating Element
MGDX6STBWGas7.0Natural GasCoil Heating Element
MEDX6STBWElectric7.0ElectricCoil Heating Element
MGDB8TWGas8.8Natural GasCoil Heating Element
MEDB8TWElectric8.8ElectricCoil Heating Element
MGDX6STAWGas7.0Natural GasCoil Heating Element
MEDX6STAWElectric7.0ElectricCoil Heating Element

Common Heating Element Issues

IssueSymptomsPossible CausesSolutionsCost of Replacement (Estimate)
No HeatDryer runs, but no heat is produced.Burned-out heating elementReplace the heating element$20 – $50
Insufficient HeatDryer doesn’t get hot enough.Partially damaged element wiresReplace or repair the heating element wiring$20 – $50
Constant HeatDryer stays hot even when off.Faulty cycling thermostatReplace the cycling thermostat$10 – $30
Inconsistent HeatHeat levels fluctuate during drying.Thermostat or thermal fuse issueReplace faulty thermostat or thermal fuse$10 – $30
Burning Smell or SmokeSmell or smoke during dryer operation.Overheating due to lint buildupClean lint buildup and inspect heating elementVaries

Table 3: Heating Element Replacement Steps

1Unplug the dryer from the power source.
2Remove the dryer’s front or rear access panel, depending on the model.
3Disconnect the wires from the old heating element.
4Remove any mounting screws or clips holding the element in place.
5Take out the old heating element carefully.
6Insert the new heating element and secure it in place.
7Reconnect the wires to the new heating element.
8Replace the access panel and secure it.
9Plug the dryer back in and test it to ensure the heat is working.
10Dispose of the old heating element properly.

 Tools and Materials

Tool or MaterialPurpose
ScrewdriverRemoving access panels and screws.
PliersHandling wires and connectors.
Replacement ElementNew heating element for the dryer.
Wire ConnectorsSecurely connecting wires.
MultimeterTesting electrical connections.
Safety GlovesProtecting hands during the process.
Lint BrushCleaning lint and debris from the dryer.

Heating Element Suppliers

Supplier NameWebsiteContact Information
AppliancePartsProswww.appliancepartspros.comPhone: 1-877-477-7278
RepairClinicwww.repairclinic.comPhone: 1-800-269-2609
PartSelectwww.partselect.comPhone: 1-888-895-1535 retailer
Home stores and online
Lowe’swww.lowes.comPhysical stores and online
eBaywww.ebay.comOnline marketplace

By following these additional tips and information, you’ll be well-prepared to tackle the heating element replacement in your Maytag Bravos dryer and keep it in top working condition.
