Maytag Centennial Dryer Troubleshooting

The Maytag Centennial dryer is a reliable and popular appliance for many households. However, like any machine, it can encounter issues from time to time. This guide will help you troubleshoot common problems with your Maytag Centennial dryer, providing step-by-step solutions.

1. Dryer Won’t Start


Troubleshooting Steps:

  1. Ensure the dryer is properly plugged into a working electrical outlet.
  2. Check the circuit breaker or fuse box to ensure it hasn’t tripped or blown a fuse.
  3. Inspect the door switch; it should click when you press it. Replace it if it’s faulty.
  4. If the door switch is functioning, but the dryer still won’t start, check the thermal fuse. If it’s blown, replace it.
  5. If none of the above solutions work, there may be an issue with the timer or control board. Consult a technician for further diagnosis and repair.

2. Dryer Doesn’t Heat Up

Possible Causes:

  • Faulty heating element.
  • Bad thermal fuse.
  • Malfunctioning thermostat.
  • Blocked or clogged exhaust vent.

Troubleshooting Steps:

  1. Make sure the dryer is set to a heat setting, not an “Air Fluff” or “Cool Down” setting.
  2. Check the lint filter for excessive lint buildup and clean it if necessary.
  3. Inspect the exhaust vent for blockages. A clogged vent can prevent proper airflow and heating.
  4. If the vent is clear, test the heating element and thermal fuse for continuity using a multimeter. Replace them if they’re faulty.
  5. Check the thermostat(s) for continuity. If they don’t have continuity, replace them.

3. Clothes Take Too Long to Dry

Possible Causes:

  • Clogged lint filter or lint screen.
  • Blocked exhaust vent.
  • Overloading the dryer.
  • Faulty heating element or thermostat.

Troubleshooting Steps:

  1. Clean the lint filter before every load to ensure proper airflow.
  2. Check the exhaust vent for obstructions regularly.
  3. Avoid overloading the dryer, as this can prevent proper circulation of hot air.
  4. If the dryer still takes too long to dry, check the heating element and thermostats for faults using a multimeter.

4. Dryer Makes Unusual Noises

Possible Causes:

  • Loose or damaged parts.
  • Foreign objects in the drum.
  • Worn drum rollers or idler pulley.

Troubleshooting Steps:

  1. Stop the dryer and inspect the drum for any loose items or foreign objects like coins, buttons, or small articles of clothing.
  2. If no foreign objects are found, check for loose or damaged parts, such as loose belts, screws, or panels. Tighten or replace as needed.
  3. Worn drum rollers or idler pulleys can cause squeaking or thumping noises. Replace them if they show signs of wear.

5. Dryer Doesn’t Tumble

Possible Causes:

  • Broken drive belt.
  • Faulty motor or motor switch.
  • Blocked blower wheel.

Troubleshooting Steps:

  1. Turn off the dryer and unplug it.
  2. Open the dryer door and manually try to rotate the drum. If it’s stiff or doesn’t move, the drive belt may be broken and needs replacement.
  3. If the drum turns freely, the issue may be with the motor or motor switch. Consult a technician for further diagnosis and repair.
  4. Check the blower wheel for obstructions. A blocked blower wheel can prevent the drum from turning.

6. Dryer Doesn’t Stop When the Cycle Ends

Possible Causes:

  • Malfunctioning timer or control board.
  • Faulty cycling thermostat.
  • Defective moisture sensor.

Troubleshooting Steps:

  1. Start by cleaning the moisture sensors if your dryer is equipped with them. Residue from fabric softeners can interfere with their functionality.
  2. Check the cycling thermostat for proper functioning. If it’s not cycling off at the correct temperature, it may need to be replaced.
  3. If the issue persists, the timer or control board might be malfunctioning. Consult a professional technician for a more accurate diagnosis and potential replacement.

7. Dryer Produces a Burning Smell

Possible Causes:

  • Lint buildup near the heating element.
  • Overheating due to blocked airflow.
  • Worn or damaged drive belt.

Troubleshooting Steps:

  1. Turn off and unplug the dryer immediately if you smell something burning. Safety should be a priority.
  2. Carefully remove the lint filter and check for lint buildup near the heating element. Clean it out to prevent further issues.
  3. Examine the drive belt for signs of wear or damage. A damaged belt may be slipping, causing friction and a burning smell. Replace it if needed.
  4. Make sure the exhaust vent is clear of obstructions, as blocked airflow can cause overheating.

8. Dryer Shuts Off Mid-Cycle

Possible Causes:

  • Overheating due to blocked exhaust or faulty thermostat.
  • Motor overload.
  • Wiring or electrical issues.

Troubleshooting Steps:

  1. Check for overheating issues by ensuring the exhaust vent is clear and the thermostat is functioning correctly. Replace the thermostat if needed.
  2. If the dryer shuts off due to a motor overload, wait for it to cool down before attempting to restart it. Overloading the dryer can strain the motor.
  3. Inspect the power cord and outlet for any loose connections or damage. Faulty wiring can cause the dryer to shut off unexpectedly.

9. Dryer Door Won’t Stay Closed

Possible Causes:

  • Worn or damaged door latch.
  • Misaligned door strike or catch.

Troubleshooting Steps:

  1. Examine the door latch for signs of wear or damage. If it’s worn, replace it with a new one.
  2. Check the door strike and catch for proper alignment. If they’re misaligned, adjust them to ensure the door stays closed securely.

10. Dryer Doesn’t Dry Evenly

Possible Causes:

  • Overloading the dryer.
  • Unevenly distributed load.
  • Blocked lint filter or exhaust vent.
  • Faulty moisture sensor or thermostat.

Troubleshooting Steps:

  1. Avoid overloading the dryer and ensure the load is evenly distributed to allow for proper airflow.
  2. Clean the lint filter and exhaust vent regularly to maintain efficient drying.
  3. Check the moisture sensor and thermostat for proper functioning. Replace them if they’re faulty.

Common Symptoms

SymptomPossible CauseTroubleshooting StepsReplacement PartAdditional Notes
Dryer won’t startDoor switch malfunctionCheck door switch, replace if neededDoor switchCheck power supply
Faulty start switchTest start switch, replace if faultyStart switchCheck control board
Blown thermal fuseTest thermal fuse, replace if blownThermal fuseCheck vent for blockage
Noisy operationWorn drum rollersReplace drum rollersDrum rollersLubricate rollers if necessary
Loose blower wheelTighten or replace blower wheelBlower wheelCheck for foreign objects
Cracked drum beltReplace drum beltDrum beltCheck drum alignment

Heat and Drying Issues

IssuePossible CauseTroubleshooting StepsReplacement PartAdditional Notes
No heatFaulty heating elementTest heating element, replace if neededHeating elementCheck thermal fuse
Burnt-out thermal fuseTest thermal fuse, replace if blownThermal fuseCheck vent for blockage
Clothes not drying wellClogged vent or exhaustClean vent and exhaust systemN/ACheck load size and type
Moisture sensor malfunctionClean or replace moisture sensorMoisture sensorCheck lint filter
Improper dryer settingsAdjust settings for appropriate dryingN/ARefer to user manual

Error Codes

Error CodeMeaningTroubleshooting StepsReplacement PartAdditional Notes
F1Control board malfunctionCheck control board connectionsControl boardPower cycle the dryer
F2Thermistor issueTest thermistor, replace if faultyThermistorCheck wiring connections
F3OverheatingClean lint filter and exhaust systemN/ACheck vent for blockage
F4Door sensor problemInspect door switch and wiringDoor switchReset the door switch
F5Drum motor issueCheck drum motor and connectionsDrum motorLubricate if motor is noisy

Drum and Rotation Problems

ProblemPossible CauseTroubleshooting StepsReplacement PartAdditional Notes
Drum not spinningBroken drive beltReplace drive beltDrive beltCheck idler pulley and motor
Faulty motorTest motor, replace if neededDrum motorCheck thermal overload switch
Uneven rotationWorn drum glides or rollersReplace drum glides or rollersDrum glides/rollersCheck drum alignment
Warped drumReplace drum or adjust alignmentDrum assemblyCheck load balance
Excessive vibrationMisaligned drumAdjust drum alignmentN/ACheck leveling of the dryer

Electrical Issues

IssuePossible CauseTroubleshooting StepsReplacement PartAdditional Notes
Tripped circuit breakerOverloaded circuitReduce load on the circuitN/ACheck wiring for damage
Short circuitInspect wiring for damageN/ALook for burnt spots or smell
Dryer shuts offHigh-limit thermostat trippedReset thermostat or replace if faultyThermostatCheck vent for blockage
Faulty power cord or plugTest cord and plug, replace if neededPower cord/plugCheck outlet voltage
Lights flicker or dimVoltage fluctuationsConsult electrician for wiring checkN/ACheck other appliances as well



Regular maintenance, such as cleaning lint filters and exhaust vents, is crucial to prevent many of these common issues with your Maytag Centennial dryer. Additionally, referring to the user manual for specific instructions and safety precautions is always a good practice when troubleshooting or performing maintenance tasks. If troubleshooting doesn’t resolve the problem, or if you are unsure about any repairs, it’s best to consult a qualified technician for professional assistance.
